Power Team 20 Ton Hydraulic 1.75" Single Acting Cylinder Spring Return Shorty RSS202

Power Team 20 Ton Hydraulic 1.75″ Single Acting Cylinder Spring Return Shorty RSS202

$132.89

SKU: SKUMCZ7xPcCkf Categories: Hydraulic Cylinders & Lifting Jacks, Power Tools Tag: Power Team SPX Brand: Power Team SPX

Description
Reviews (0)

Additional Details

Power Team
Power Tech plated piston rods and gland nuts resist scoring and corrosion.
Heavy duty return spring (except for double-acting models) provides fast piston return & low collapsed height.
Coupler on 10 thru 50 ton models is angled upward 5 for added clearance.
Grooved piston top keeps load from sliding.
Cylinders can be dead-ended at full capacity.
Removable carrying handles on 100 ton and 250 ton models.
Order No.: RSS202
Cyl Cap. (tons) : 20
Stroke (in.) : 1 3/4
Oil Cap. (cu. in.) Push: 7.7
Oil Cap. (cu. in.) Return:
Bore Dia. (in.) : 2 3/8
Cylinder Effective Area (sq. in.) Push: 4.43
Internal Press at Cap. (psi) Push: 9;029
Tons at 10000 (psi) Push: 22.1
Weight (lbs.) : 9.9
Retracted Height (in.) : 3 3/4
Extended Height (in.) : 5 1/2
Outside Dia. (in.) : 3 9/16
Base to Port (in.) : 5/8
Piston Rod Dia. (in.) : 2 5/32

Specifications

More Information
OPT SKU	PTRSS202
MPN	RSS202
UPC/GTIN	662536003568
Product Type	Cylinder Rams Single Acting
Google Category	Business & Industrial > Material Handling
Stroke	1-3/4″
Tonnage	20-Ton
Shipping Weight	14.00
