Chicago Pneumatic #5 Spline Impact Wrench 0611-D28L

• Metric	Imperial
  Model	CP0611-D28L
  Part number	6151590170
  Actual air consumption	32 l/s	68 cfm
  Air inlet thread size	1/2 “
  Blows per minute	1020
  Box dimensions	505x240x145 mm
  Clutch type	2-jaw clutch
  Free speed	3500 rpm
  Free speed air consumption	55 l/s
  Handle type	D-Handle
  Length	360 mm
  Maximum Torque (reverse)	3790 Nm	2800 ft.lbs
  Min. hose size		1 “
  Net weight	10.4 kg	22.9 lb
  Side to center	46 mm	1.81 “
  Socket retainer	Hole
  Sound Power	110 db(A)
  Sound pressure	99 db(A)
  Square drive	#5 spline “
  Vibration	18 m/s²
  Vibration ISO	ISO-28927-2
  Vibration uncertainty (K)	4.1 m/s²
  Working Torque Range (fwd)	1;220 – 2;440 Nm	900 – 1;800 ft.lbs

“
