BVA 12 Ton 1.61″ Stroke Hollow Hole Single Acting Cylinder No Threads HC1202XT

• BVA Hydraulics
• BVA 12 Ton 1.61 Stroke Hollow Hole Single Acting Cylinder No Threads HC1202XT
• Ideal for pulling and pushing applications
• Heavy duty compression spring
• Dual wipers help prevent contamination
• Collar thread protector
• High flow coupler with dust cap
• XT cylinders do not come with internal rod threads
• 60 and 100 ton models are equipped with carrying handles
• Cylinder Capacity (Tons): 12
• Stroke (in.): 1.61
• Model Number: HC1202XT
• Cylinder Effective Area In2): 2.91
• Pressure at Capacity: 8;236
• Oil Capacity (in3): 4.70
• Weight (lbs.): 6.2
• Min Height (in.): 4.74
• Max Height (in.): 6.36

“
